[Automotive Manufacturing and Testing Technology] 1.Mechanical Drawing

Lesson Code: TCEN2026H043

Clicks：

LIKE

Academic Hours

1.70hours

Publish Date

Feb 2026

Lecturer

1. WEN XiaNeijiang Vocational & Technical College

2. LAN KaiNeijiang Vocational & Technical College

3. TANG JianminNeijiang Vocational & Technical College

4. PU ShanshanNeijiang Vocational & Technical College

General Introduction

This course aims to cultivate students’ abilities in reading and producing standardized mechanical drawings. It primarily teaches the principles of engineering projection, the application of national standards (GB), and the use of modern computer-aided drafting software.

Students will be able to apply these principles and skills to engineering practice, forming a solid graphical communication foundation for subsequent professional courses and for undertaking technical work in mechanical design, manufacturing, and related positions.

This Course is for

1. Helping learners master the fundamental theories and graphical principles of orthographic projection;
2. Familiarizing learners with the basic provisions of the national standard for Mechanical Drawing and the representation methods of common parts, standard parts, and typical components and assemblies;
3. Enabling learners to proficiently read and produce part drawings and assembly drawings of moderate complexity;
4. Equipping learners with the ability to analyze and solve spatial geometry problems using projection principles;
5. Helping learners develop rigorous, meticulous, and standardized engineering drawing practices, and instilling a strong awareness of standardization and a spirit of craftsmanship;
6. Helping learners lay a solid foundation for spatial thinking and basic engineering communication skills to support subsequent professional courses and future job roles.

Learning Materials

1. Corresponding PPT
2. Online Course Video
3. Simulation Question Banks

Recognized By

Benefits of Learning

1. Being able to master drawing standards and specifications, exercise precise control over dimensions, tolerances, and symbols, and ensure that drawings are universal, standardized, and authoritative;
2. Demonstrating strong spatial visualization abilities, including the capability to transform three-dimensional mechanical structures into two-dimensional drawings and to reconstruct physical forms from drawings;
3. Possessing essential mechanical expertise to understand part functions and assembly relationships, ensuring that drawings comply with standards while meeting practical production requirements and providing reliable references for subsequent manufacturing processes;
4. Possessing a rigorous, meticulous work style and a strong craftsmanship spirit with a commitment to excellence.
